LINJA FLAT IP20 24VDC 28,8W

Download datasheet

SPECIFICATIONS

SMD LED(S) 360 per meter
MAX. POWER 28,8 Watt 1,2Amp per meter
BEAM ANGLE 120°
CRI 90+(opal) 75+(Black)
VOLTAGE 24 VDC
GEAR / DRIVER Not included
MATERIAL Aluminium / Pc
MAX. LENGTH 50/6000 mm (1 profile/ 1 defuser)
WEIGHT (KG) 1,7
IP 20
ORDER PER METER
OPTIONS: INTERNAL DRIVER = ORDER SEPARATELY : LINJA POWER SUPPLY 24VDC 20W P/M ORDER CODE : 800241070030
211,00 €

Contact Us

MODELS

Article n° Description Colour Kelvin Lumen LDT
046281112209 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING BLACK STRUC. 2200 1400 -
046281122209 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING BLACK STRUC. 2200 1400 -
046281112709 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING BLACK STRUC. 2700 1400 -
046281122709 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING BLACK STRUC. 2700 1400 -
046281113009 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING BLACK STRUC. 3000 1600 -
046281123009 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING BLACK STRUC. 3000 1600 -
046281114009 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT OPAL PC - CLIPS MOUNTING BLACK STRUC. 4000 1800 -
046281124009 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT OPAL PC - MAGNETS MOUNTING BLACK STRUC. 4000 1800 -
046281112210 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING BLACK STRUC. 2200 1120 -
046281122210 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING BLACK STRUC. 2200 1120 -
046281112710 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING BLACK STRUC. 2700 1120 -
046281122710 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING BLACK STRUC. 2700 1120 -
046281113010 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING BLACK STRUC. 3000 1280 -
046281123010 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING BLACK STRUC. 3000 1280 -
046281114010 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT BLACK PC - CLIPS MOUNTING BLACK STRUC. 4000 1440 -
046281124010 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT BLACK PC - MAGNETS MOUNTING BLACK STRUC. 4000 1440 -
046281112206 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING WHITE STRUC. 2200 1400 -
046281122206 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING WHITE STRUC. 2200 1400 -
046281112706 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING WHITE STRUC. 2700 1400 -
046281122706 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING WHITE STRUC. 2700 1400 -
046281113006 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING WHITE STRUC. 3000 1600 -
046281123006 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING WHITE STRUC. 3000 1600 -
046281114006 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT OPAL PC - CLIPS MOUNTING WHITE STRUC. 4000 1800 -
046281124006 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT OPAL PC - MAGNETS MOUNTING WHITE STRUC. 4000 1800 -
046281112207 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING WHITE STRUC. 2200 1120 -
046281122207 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING WHITE STRUC. 2200 1120 -
046281112707 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING WHITE STRUC. 2700 1120 -
046281122707 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING WHITE STRUC. 2700 1120 -
046281113007 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING WHITE STRUC. 3000 1280 -
046281123007 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING WHITE STRUC. 3000 1280 -
046281114007 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT BLACK PC - CLIPS MOUNTING WHITE STRUC. 4000 1440 -
046281124007 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT BLACK PC - MAGNETS MOUNTING WHITE STRUC. 4000 1440 -
046281112228 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING NATURAL ANODIZED 2200 1400 -
046281122229 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING NATURAL ANODIZED 2200 1120 -
046281112728 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING NATURAL ANODIZED 2700 1400 -
046281122728 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING NATURAL ANODIZED 2700 1400 -
046281113028 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING NATURAL ANODIZED 3000 1600 -
046281123028 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING NATURAL ANODIZED 3000 1600 -
046281114028 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT OPAL PC - CLIPS MOUNTING NATURAL ANODIZED 4000 1800 -
046281124028 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT OPAL PC - MAGNETS MOUNTING NATURAL ANODIZED 4000 1800 -
046281112229 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING NATURAL ANODIZED 2200 1120 -
046281122228 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING NATURAL ANODIZED 2200 1120 -
046281112729 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING NATURAL ANODIZED 2700 1120 -
046281122729 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING NATURAL ANODIZED 2700 1120 -
046281113029 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING NATURAL ANODIZED 3000 1280 -
046281123029 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING NATURAL ANODIZED 3000 1280 -
046281114029 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT BLACK PC - CLIPS MOUNTING NATURAL ANODIZED 4000 1440 -
046281124029 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT BLACK PC - MAGNETS MOUNTING NATURAL ANODIZED 4000 1440 -
046281112212 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING ANY RAL 2200 700 -
046281122212 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING ANY RAL 2200 1400 -
046281112712 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING ANY RAL 2700 1400 -
046281122712 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING ANY RAL 2700 1400 -
046281113012 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - CLIPS MOUNTING ANY RAL 3000 1600 -
046281123012 LEDPROFILE LINJA INT. WARM WHITE - FLAT OPAL PC - MAGNETS MOUNTING ANY RAL 3000 1600 -
046281114012 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT OPAL PC - CLIPS MOUNTING ANY RAL 4000 1800 -
046281124012 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT OPAL PC - MAGNETS MOUNTING ANY RAL 4000 1800 -
046281112213 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING ANY RAL 2200 1120 -
046281122213 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING ANY RAL 2200 1120 -
046281112713 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING ANY RAL 2700 1120 -
046281122713 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING ANY RAL 2700 1120 -
046281113013 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - CLIPS MOUNTING ANY RAL 3000 1280 -
046281123013 LEDPROFILE LINJA INT. WARM WHITE - FLAT BLACK PC - MAGNETS MOUNTING ANY RAL 3000 1280 -
046281114013 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT BLACK PC - CLIPS MOUNTING ANY RAL 4000 1440 -
046281124013 LEDPROFILE LINJA INT. NATURAL WHITE - FLAT BLACK PC - MAGNETS MOUNTING ANY RAL 4000 1440 -
COLOR WHITE STRUC. or BLACK STRUC. or ANY RAL or NATURAL ANODIZED
LUMEN OUTPUT 2200 or 2700 or 3000 or 4000
TO MOUNT CLIPS or MAGNET
DIFFUSOR PC FLAT OPAL or PC FLAT BLACK
MOUNTING SURFACE or RECESSED
FIXATION CEILING or WALL
APPLICATION HOME INTERIOR
WATT 28,8
